PSO Hy-Trans Transformer Oil
PSO

PSO Hy-Trans Transformer Oil

Transformer Oil

Quoted on request. We reply with price and stock within 24 business hours.

Pack Size210 L
Enquire Now

Buy online or request a quote. Minimum order: one piece. Request Datasheet

  • Authorized supply. Ask us to confirm the stock source and batch documents.
  • Same-day delivery in Karachi. 3–4 working days elsewhere in Pakistan.
  • Advance payment by bank transfer or Easypaisa.
Description

Please CALL or CHAT NOW us for quotation and availability.

Transformer Oil is a selected refined mineral oil having the properties of insulating coils of transformers, switches and circuit breakers both electrically and thermally. The oil must have very low viscosity and high chemical and oxidation stability with Flash Point of 275 - 325° F.

Transformer Oils are prepared by careful selection of crude oil and greater degree of refining. The oil is refined in such a way that it imparts exceptional high oxidation and high resistance to gas formation. The oil shows high degree of dielectric properties and resistance to power losses. Well-stabilized methods are used to control the quality of the oil in order to meet international standard specification and maximum trouble free services. Transformer Oil is made for transformers as well as for insulating switchgears and circuit breakers.

Transformer Oils have two main functions, insulation and cooling. These two functions are both important and good transformer oils must possess these properties over a long period of time despite temperature increase, contact with metals etc. The careful selection and optimum refining of crude oils are the only way to develop these properties. HY-TRANS is produced according to IEC 60296 specification suitably adjusted for tropical areas. It also meets the specification of BS - 148.

PHYSICAL AND CHEMICAL PROPERTIES


TEST METHOD METHOD TITLE Spec
IEC-296 Appearance Visual
ISO-2049 Color (ASTM)
ISO-12185 Density at 20 oC  Kg/dm3 0.895(Max)
ISO-3104 Viscosity Kinematic at 40 oC cSt 12(Max)
ISO-3104 Viscosity Kinematic at -20 oC cSt (Lcset) 1800(Max)
ISO-5662
DIN 51353		 Corrosive Sulphur Non Corrosive
IEC-62021-1 Total Acid No mg KOH/gm (Potentiometric) 0.01(Max)
ISO-2719 Flash Point PMCC oC 135(Min)
ISO-3016 Pour Point oC -30(Max)
IEC-60156 Di Electric Strength K.V. 30(Min)
IEC-61125C Oxidation stability
  (a) Sludge Value % WT 0.8(Max)
  (b) Acidity after Oxidation mg KOH/gm 1.2(Max)
  (c) DDF @ 90 °C 0.500(Max)
IEC-60814 Water Content (ppm) 30(Max)
IEC-60247 Tangent Delta at 90 °C, 0.005(Max)
ISO-6295 Interfacial Tension mN/m N.G.R
IEC-61198 2-Furfural content (ppm) 0.1(Max)
BS-2000 Part-346 PCA 3%(Max)
IEC-61619
EPA 9079		 PCB content* N.D
IEC-60666 Antioxidant additive** U/T/I
